1. Compatible with 1080p Lorex HD DVRs only. For the most up-to-date list of compatible recorders, visit www.lorextechnology.com/support
2. Full color nighttime video typically switches to black & white IR night vision below 1 lux to ensure optimal low-light image quality.
3. This camera features an ultra-low light sensitive image sensor and therefore does not feature Infra-Red LEDs. The camera requires ambient lighting (for example, street/ building lighting, star or moon light) to render a night time image. In total darkness (zero Lux), the camera will not produce a night time image and therefore the camera should not be installed in completely dark areas.
4. Not intended for submersion in water. Installation in a sheltered location recommended.
All trademarks belong to their respective owners. No claim is made to the exclusive right to use the trademarks listed, other than the trademarks owned by Lorex Corporation. We reserve the right to change models, configurations or specifications without notice or liability. Product may not be exactly as shown. Images are simulated.
Features

The LZV2622 1080p HD Pan-Tilt-Zoom (PTZ) camera is a perfect mix of DIY simplicity and professional performance. Not only can this powerful security camera capture HD 1080p video, it has fast PTZ capabilities that let you move the lens in virtually any direction. These movements can be easily controlled from your DVR, computer or smartphone. This security camera also has advanced Color Night Vision™ (CNV) technology, which adds a new dimension of detail to night time security video. Install this security camera on a ceiling or use the included mounting bracket to attach it to a wall. It is fully weatherproof and is perfect for monitoring large outdoor areas.
LZV2622
SPECIFICATIONS
PTZ camera
Pan-Tilt-Zoom (PTZ) camera for HD DVRs
1080p
RESOLUTION
1920 x 1080 HD resolution
4×
OPTICAL ZOOM
For viewing fine details in enhanced definition

What is a PTZ security camera?
A PTZ camera can adjust its field of view left and right (panning), up and down (tilting), and in or out (zooming). This allows the security camera to see in virtually any direction, and focus on distant objects. PTZ features on your camera include:
- Advanced 355° rotation
- 90° tilt range
- Rapid 100° per second panning speed
- Preset viewing tours for a wide range of continual coverage

Powerful zoom abilities
Don't miss out on important details (such as facial features) - even if they are in the distance. Zoom in without losing picture quality thanks to 4× optical zoom and a powerful 16× digital zoom. Use this zoom ability on-the-go or as part of a preset pattern.

Superior detail with HD 1080p resolution
See the clarity that HD 1080p video has to offer. This camera uses an advanced 2.1 megapixel image sensor that is capable of delivering incredible high definition video and accurate color reproduction.
Don't be left colorblind at night
The LZV2622 security camera uses our revolutionary Color Night Vison (CNV) technology. This important feature:
- Produces full-color video, even in low-light conditions*
- Adds an additional level of visual information that can help identify people or objects
- Increases contrast for easier detection
*Note: ambient light is needed for CNV™ operation. ClearNight technology is also featured on this security camera to provide exceptional black and white viewing, for when Color Night Vision™ is not in use.


Easy and clutter-free installation
This MPX security camera uses a siamese coaxial cable (60ft) to connect to a high-definition DVR (available here). This siamese cable can carry both power and video up to 300 feet. For larger properties, you can extend the video signal up to 800 feet.

Extreme temperature tolerance
This rugged PTZ camera is built for the outdoors. It is fully weatherproof (IP66-rated) and can stand up against rain, snow, and freezing temperatures as low as -22°F (-30°C). The included wall mount bracket is also fully weatherproof, and durable enough for outdoor installation.

Full Metal Camera Housing
Built from a solid unibody metal housing, the LZV2622 allows for durability while still maintaining a lightweight design. The corrosion-resistant aluminum body makes this camera perfect for both indoor and outdoor use, protecting it from even the harshest of weather; rain, snow, or hail. Engineered from the same material that is used in construction of airplanes and cars, this Lorex camera is strong enough to withstand large impacts unlike conventional plastic security cameras.
Video
What's Included?

- High definition 1080p image sensor1
- Powerful 4× optical zoom and 16× digital zoom to focus in on even the finest details
- Color Night Vision™ delivers full color nighttime video for improved recognition of objects low light conditions2
- ClearNight imaging for improved low light performance and improved recording efficiency3
- 355° pan rotation for complete area coverage. Fast 100° per second panning speed
- Control PTZ camera movement and transmit video over a single coax cable
- Program preset viewing points and tours when connected to a DVR
- Remote control of the PTZ camera using a smartphone or tablet when connected to a DVR
- Day/Night mode: picture automatically switches to B&W delivering better clarity in low light conditions
- Infrared cut filter ensures accurate color representation
- Weatherproof (IP66-rated) camera with extreme temperature performance (-22° ~ 140°F / -30° ~ 60°C)4
- Wall mount bracket & 60ft (18m) extension cable included for installation flexibility
