• 2K HD (2 x 1080p) MPX Security DVR - 16 Channel, 3TB Hard Drive, Works with Older BNC Analog Cameras, CVI, TVI, AHD - Lorex Corporation
  • 2K HD (2 x 1080p) MPX Security DVR - 16 Channel, 3TB Hard Drive, Works with Older BNC Analog Cameras, CVI, TVI, AHD - Lorex Corporation
1 2
View full details

2K HD (2 x 1080p) MPX Security DVR - 16 Channel, 3TB Hard Drive, Works with Older BNC Analog Cameras, CVI, TVI, AHD

2K HD (2 x 1080p) MPX Security DVR - 16 Channel, 3TB Hard Drive, Works with Older BNC Analog Cameras, CVI, TVI, AHD

SKU: DV8163W
DV7082

This powerful 16-channel 2K resolution Digital Video Recorder (DVR) is just what you need to protect your business or your house. With easy security camera connections and a straightforward user interface, this DVR is a perfect solution to start or upgrade your MPX security camera system. Designed to work with advanced megapixel (MPX) security cameras, it is capable of recording exceptionally detailed 2K resolution video and smooth on-screen movement.

DV8163

SPECIFICATIONS

16

CHANNELS

DVR supports up to 16 cameras

2K

RESOLUTION

Double the resolution of HD 1080p

3TB

HARD DRIVE

Maximum Capacity 1 x 8TB hard drives

Lorex Cloud App

Lorex Cloud™ Enabled

2K superHD security DVR

2K resolution security footage

In order to capture the details you need, you need a security DVR that can handle recording high quality security footage. Thankfully, this DVR is capable of recording crystal clear 2K resolution footage on all channels*. This resolution is double that of 1080p, and will provide you with richer detail and higher quality digital zooms.



*4MP High Definition MPX cameras are required to take advantage of 4MP recording.

2k vs 1080p

The 2K difference

SuperHD 2K video offers clear identification and exceptional detail, ensuring that nothing is left to the imagination. This higher resolution (2592 × 1520 pixels - compared to 1920 × 1080) will provide you with a better chance to capture important details, such as faces. Doubling the amount of pixels will also vastly improve the quality of digital zooms when reviewing footage. This means that if you see something in the distance of your footage, you will be able to digitally zoom in twice as far before the image starts to blur together.

30 FPS DVR

Real-time 30FPS recording rate

Choose to record 2K resolution at 12 frames per second (FPS) or record at a real-time 30 frames per second (FPS) rate at 1080p resolution. This high frame rate provides real-time motion, ensuring that you don't miss the best moments.

Lorex Cloud App

Remote viewing from your mobile with Lorex Cloud™

The DV800 Series DVR is designed for use with our innovative hassle-free Lorex Cloud™ app Using Lorex Cloud™, you can quickly and easily view your security system remotely from your smartphone or tablet. There are no difficult port forwarding or other complicated network setups either. Simply download the free app, scan the QR code on the DVR and your cameras will appear for you to monitor (or review footage). You can also program the app to send you motion-activated push notifications and email alerts with screenshot attachments straight to your phone to keep you connected to your property at all times.

Works With

Lorex Cloud app compatibility
Lorex cloud app works with
BNC security camera connection

Single cable camera connection

Standard siamese BNC cabling is used to connect MPX security cameras. This BNC cable provides both video and power transmission up to 300ft for an easy-to-install process that will have your surveillance system up and running in no time. If needed, MPX cameras can be installed further than 300ft away, but the camera will need to be plugged in directly to an electrical outlet.

DVR supports all IP cameras

Supports a full range of MPX, analog, CVI, and wireless cameras

This DVR is compatible with our full line of high definition MPX and wireless security cameras (excluding wire-free security cameras). It is also backward compatible, meaning older analog and CVI security cameras will still work as well.


Camera Compatibility Chart

Upgrade older DVR systems

The technology within a Lorex DVR has changed drastically over the past few years. Thankfully the way in which camera cables are connected to it has not. This means that it is extremely easy to upgrade your older DVR security system to a new one. You can also easily swap your older analog cameras for brand new HD ones using the same cabling.

24/7 heavy-duty professional HDD for security systems

Reliable security grade hard drive

DVRs such as this are capable of working 24/7 without a break. Thankfully, so is the 3TB hard drive within it. Lorex uses security certified hard drives that are manufactured specifically to meet the high workload demands of continuous security monitoring. This means that you can rely on this professional grade hard drive to safely store weeks (or even months) of security footage. It is also possible to manually upgrade the hard drive within the DVR to a hard drive up to 8TB in size.



Visit our Hard Drive Calculator to estimate your desired specifications.

DVR recording modes - continuous, scheduled, motion

Different recording modes

This DVR has three different recording options to suit your needs. You can record footage continuously, during scheduled times, or when movement is detected. These options can be customized with each of your security cameras, which means you can have your most important camera recording all of the time while lower activity cameras can be programmed only to record on motion. To be safe, this DVR includes a pre-recording function that goes along with the motion recording option. This feature will go back to record the five seconds before the motion is detected, so you never have to worry about missing those first vital moments.

DVR with auto-recovery

Automatic overwrite

You don't have to worry about storage management with this DVR. It is designed to automatically overwrite the oldest data with the newest data when the hard drive becomes full. This means that you will never run out of storage space. Just make sure to save any important footage before it gets overwritten.

auto-recovery DVR watch dog

Automatic recovery after power failure

An auto-recovery feature will automatically reboot your DVR once it regains power. This means that you don't have to do a thing - your system will simply start recording again within minutes. A Watch Dog function is also built-in to this DVR that continuously monitors the system for potential system errors. If it detects a critical error, Watch Dog will automatically reboot the system, which helps ensure system stability, keeps your cameras recording, and prevents future system failures.



Image resolution comparison

2K 4mp Comparison Chart
  4K HDIP 2K HDIP HD 1080 Digital IP Super HD 4mp DVR HD 1080 Analog BNC
Recording 8mp (3840

What's Included?

DV8163

16 channel, HD 2K security DVR
  • True high definition 1080p recording on all HD cameras1
  • Backwards compatible with standard analog cameras
  • 24/7 security-grade hard drive
  • Continuous, scheduled and motion recording
  • PTZ cameras supported, remote control through App1
  • H.264 video compression2
  • HDMI cable included for simple connection to HD TVs3
  • Accurate time stamps with NTP & daylight savings time
  • Click and drag digital zoom in live view and playback
  • 2 video outputs (HDMI & VGA) to connect multiple monitors
  • Instant USB backup of live video from selected camera
  • Automatic firmware upgrade
  • 3-Step remote view with Lorex Cloud4
  • PC and Mac compatible5
  • Instant mobile viewing on smartphones and tablets5
  • Advanced apps with live viewing, playback, video recording, and snap shot
  • Mobile push notifications of motion events and email alerts
  • Dual streaming to conserve bandwidth

Each DV8163 Includes:

1 × DVR
1 × HDMI Cable
1 × Remote Control
1 × Power Adapter
1 × Mouse
1 × Ethernet Cable
Quick Start Guides

1. Compatible with Lorex 1080p and 720p wired HD cameras only. For a list of compatible cameras, please visit lorextechnology.com/support
2. Recording time may vary based on recording resolution & quality, lighting conditions and movement in the scene.
3. HDMI output (1920×1080) HD for high definition multi-channel live viewing only. 1080p recording resolution is limited to a maximum of 1920×1080 per channel. Image quality and resolution is dependent on the type of camera connected to the DVR.
4. Requires a high speed internet connection and a router (not included). A minimum upload speed of 1Mbps is required for the best video performance. Up to 2 devices may connect to the system at the same time.
5. For the latest list of supported apps and devices, please visit www.lorextechnology.com/support

All trademarks belong to their respective owners. No claim is made to the exclusive right to use the trademarks listed, other than the trademarks owned by Lorex Technology Inc. We reserve the right to change models, configurations or specifications without notice or liability. Product may not be exactly as shown. Images are simulated.
